SIEMENS QAK36.596/109 IMMERSION TYPE TEMPERATURE SENSOR

General Information:
The SIEMENS QAK36.596/109 is an active immersion temperature sensor designed for industrial and commercial HVAC applications. It is primarily used for monitoring liquid temperatures and optimizing energy control in heating and cooling systems.

Technical Specifications:

• Model: QAK36.596/109

• Sensor Type: Active (with integrated electronic output)

• Sensing Element: Electronic sensor – analog signal output

• Output Signal: 0…10 V DC or 4…20 mA (depending on variant)

• Measuring Range: 0…100 °C

• Immersion Length: 100 mm

• Housing Material: Stainless steel probe, plastic terminal head

• Protection Class: IP65

• Cable Entry: M16 cable gland

• Power Supply: 24 V AC/DC

• Mounting Type: Immersion well or direct pipe installation

Applications:

• Temperature control in HVAC systems

• Temperature monitoring in boilers, heat exchangers, and tanks

• Energy automation systems

• Liquid temperature measurement in industrial processes

Advantages:

• Easy integration with control systems via analog output

• Wide measuring range

• Robust and long-lasting construction

• High protection class suitable for outdoor or harsh environments
