SIEMENS QAE2174.015 IMMERSION TYPE TEMPERATURE SENSOR

General Information:
SIEMENS QAE2174.015 is an active-type immersion temperature sensor designed for accurate temperature monitoring in HVAC and industrial applications. With a 0…10 V analog output, it provides seamless integration with building automation systems. The extended immersion length is suitable for larger systems.

Technical Specifications:

• Model: QAE2174.015

• Sensor Type: Active (0…10 V output)

• Output Signal: 0…10 V DC

• Measuring Range: -30°C to +130°C

• Immersion Length: 150 mm

• Power Supply: 15…35 V DC or 24 V AC ±20%

• Protection Rating: IP65

• Mounting Type: Compatible with immersion pockets

• Cable Entry: M16 cable gland

• Housing Material: Stainless steel probe, impact-resistant plastic housing

• Application Areas:

  • Industrial boilers

  • Water heaters

  • Chiller systems

  • Heat exchangers

  • HVAC control systems

Advantages:

• Accurate measurement over a wide temperature range

• Compatible with standard building management systems

• IP65 rating for harsh environments

• 150 mm immersion for deeper system integration
