SIEMENS QAE2115.015 IMMERSION TYPE TEMPERATURE SENSOR

General Information:
The SIEMENS QAE2115.015 is a passive immersion temperature sensor designed for use in pipe systems to measure liquid temperature. It is suitable for integration into HVAC and building automation systems, delivering precise and reliable temperature data.

Technical Specifications:

• Model: QAE2115.015

• Sensor Type: Passive

• Sensing Element: LG-Ni 1000 (1000 ohms at 0 °C)

• Measuring Range: -30 °C to +130 °C

• Immersion Length: 150 mm

• Cable Entry: M16 x 1.5 cable gland

• Mounting Type: G1/2" threaded (for use with immersion pocket)

• Protection Class: IP65

• Housing Material: UV-resistant plastic

• Applications:

  • Heating and cooling systems

  • Building automation and BMS

  • Boiler, chiller, and pipeline temperature monitoring

  • Providing feedback signals to control systems

Advantages:

• Wide measurement range

• Rugged and compact design

• Compatible with standard LG-Ni 1000 input systems

• Easy installation, long service life
