SIEMENS QAE2115.010 IMMERSION TYPE TEMPERATURE SENSOR

General Information:
The SIEMENS QAE2115.010 is a passive immersion temperature sensor designed for precise monitoring of liquid temperatures in pipes and vessels, typically used in HVAC and building automation systems. It provides temperature feedback directly to control systems.

Technical Specifications:

• Model: QAE2115.010

• Sensor Type: Passive

• Sensing Element: LG-Ni 1000 (Ni 1000 ohms at 0 °C)

• Measuring Range: -30°C to +130°C

• Immersion Length: 100 mm

• Cable Entry: M16 x 1.5 cable gland

• Threaded Connection: G1/2" (to be used with an immersion pocket)

• Protection Class: IP65

• Housing Material: UV-resistant plastic

• Applications:

  • Building management systems

  • Heating and cooling systems

  • Boiler and chiller line monitoring

  • Feedback signal source for automation controllers

Advantages:

• Compact and robust design

• Wide application range

• Compatible LG-Ni 1000 sensing element

• Easy installation and commissioning
