Pressure range |
0~10kPa…2.5MPa |
||
|
Static pressure |
20MPa(Max.) |
||
|
Pressure reference |
Differential pressure |
||
|
Supply & output |
4~20mA(16~36VDC) 1~5V, 0~5V(12~36VDC) |
||
|
Accuracy |
0.5%FS(typ.) |
||
|
Temp. drift |
1.5%FS(@-10℃~70℃） |
||
|
Response time |
1ms(Up to 90%FS) |
||
|
Service life |
≥10×106 pressure cycles |
||
|
Ambient temp. |
-10℃~70℃ |
||
|
Medium temp. |
-10℃~70℃ |
||
|
Storage temp. |
-40℃~125℃ |
||
|
EMC-interference |
IEC 61000-6-3 |
||
|
EMC-immunity |
IEC 61000-6-2 |
||
|
Insulation resistance |
200MΩ/250VDC |
||
|
Shock resistance |
100g(11ms) |
||
|
Protection |
IP65 |
||
|
Material |
304 |
||
|
Max. mounting torque |
25Nm |
