SIEMENS QRA10M.C UV.PHOTOCELL LAMP

General Description:
The SIEMENS QRA10M.C is a heavy-duty, UV-sensitive flame detector with a metal body and optional cooling capability. It is designed for use in industrial gas and oil burners, especially in high-temperature and high-vibration environments.

Technical Specifications:

• Detection Type: Ultraviolet (UV)

• Wavelength Sensitivity: 190 – 270 nm

• Housing: Metal, suitable for air or water cooling

• Cooling: Air or water-cooled (if required)

• Power Supply: Provided through Siemens flame safeguard units

• Operating Temperature: -20 °C to +250 °C

• Protection Class: IP65

• Connection Type: Threaded connector

• Cable Length: 3 m standard (custom lengths available)

• Compatible Controllers: LFL, LME, LGK, and LMV series

Applications:

• Large-capacity gas/oil burners

• Steam and hot water boilers

• Industrial process heating systems

• Power generation, chemical, textile, and food industries

Advantages:

• High resistance to temperature and vibration

• Robust metal housing

• Ideal for tough industrial conditions

• Accurate and reliable flame detection

• IP65 protection ensures durability
