Ema SM1002 Speed Monitor

General Features

Speed Monitör

- User can easily set the frequency, rotation rate, pulse and the signal

- Mounting: DIN-Rail

- Output: PNP, NPN, Relay, 0/4..20mA, 0-10V

- Display: LCD

- Connection: Dual-chamber terminals

- Protection classification: IP50

- It can be used for wind power, also the rotation of conveyor belt, motor, wind turbines paddles and the direction of electric machines.

Technical Specifications

Supply Voltage : 230AC/24DC

Temperature : -20 to 60

Introduction : 2

Function input : PNP/NPN PNP/NPN

Setting range : 1-60000 rpm

Setting Range : 0.1-1000 Hz

Analog Output : 0

Relay Output : 2

Transistor Output : 2

Display : Yes

Protection : IP50
