SIEMENS LMO14.113C2 BURNER AUTOMATIC

General Description:
The SIEMENS LMO14.113C2 is a microprocessor-based burner control unit designed for use with low to medium capacity oil burners. It complies with EN 230 and offers reliable burner startup, flame supervision, and error diagnosis.

Technical Specifications:

• Model: LMO14.113C2

• Power Supply: 230 V AC, 50 Hz

• Burner Type: Oil burners (up to 30 kg/h)

• Timing Functions:

  • Pre-purge time: 13 seconds

  • Safety time: 10 seconds

• Flame Monitoring: By ionization electrode or photocell (QRB...)

• Reset: Manual

• Mounting Type: DIN rail or screw-mounted panel installation

• Operating Temperature: -20 °C ... +60 °C

• Protection Class: IP40

• Additional Feature: LED display for fault codes

Applications:

• Residential boiler systems

• Commercial oil burner installations

• Industrial heating systems

Advantages:

• Safe and fast burner ignition control

• LED indicator for error diagnostics

• Compact and robust design

• Easy installation and maintenance
